Substandard road bridges in Great Britain – 2020 data29 Jan 2021

The number of substandard road bridges managed by councils across Great Britain is increasing.Local authorities in England, Scotland and Wales have identified 3,105 bridges – defined as structures over 1.5m in span – as being substandard.This was 1.6% up on the 3,055 figure twelve months before.

Substandard means unable to carry the heaviest vehicles now seen on our roads, including lorries of up to 44 tonnes. Many of the substandard bridges are subject to weight restrictions. Others will be under programmes of increased monitoring or even managed decline.

The analysis was carried out by the RAC Foundation and uses responses to FOI requests made by the Foundation in October 2020 to 206 local highways authorities.

The analysis is based on data provided by 199 councils out of the 206 asked.

Between them the councils are responsible for maintaining 71,656 bridges meaning 4.3% of the inventory is substandard.

Councils also reported that, at the time they responded in Autumn 2020, ten bridges across Great Britain had fully collapsed in the previous 12 months. A further 30 had partially collapsed.

Of the 10 full collapses, 7 were in Aberdeenshire. Caerphilly, Derbyshire and Dumfries & Galloway had 1 each.

The 30 partial collapses were in: Powys (6); Conwy (5); Denbighshire (3); Dumfries & Galloway (2); North Yorkshire (2); Perth and Kinross (2); and Barnet, Buckinghamshire, Fife, Gwynedd, Lincolnshire, Merton, Neath Port Talbot, Peterborough, Somerset and Stirling (one each).

Despite these failures the analysis shows an apparent large decline in the number of bridges being assessed for damage caused by river flow.

2019-20 2018-19
Number of BD97 Stage 1 scour assessments 2687 3936
– based on (authorities) 31 37
– based on (bridges) 20618 22771
% of bridges that received Stage 1 scour assessments 13% 17%
Number of BD97 Stage 2 scour assessments 79 235
– based on (authorities) 13 11
– based on (bridges) 9243 9429
% of bridges that received Stage 2 scour assessments 0.9% 2.5%


Typically, a bridge which has its foundations in a watercourse should receive an initial Stage 1 scour assessment which can lead to a Stage 2 scour assessment if any faults or concerns are uncovered.

Between them, councils say they would ideally want to bring 2,256 (73%) of the 3,105 substandard bridges back up to full carrying capacity.

However, budget restrictions mean they anticipate that only 392 of these will have the necessary work carried out on them within the next five years.

The estimated cost to bring all the substandard bridges back up to perfect condition is £985 million (down slightly on the £1.1 billion figure of a year earlier).

The study reveals that the one-time cost to clear the maintenance backlog on all 71,656 bridges is £5.54 billion, down fractionally from the previous year’s figure of £5.55 billion.

The survey of local highways authorities was carried out by the RAC Foundation with the help of the National Bridges Group of ADEPT (the Association of Directors of Environment, Economics, Planning and Transportation).

The ten councils in Britain with the highest number of substandard bridges are:

Local Authority Number of bridges Number of substandard bridges Proportion of substandard bridges
Devon 2716 233 9%
Essex 961 165 17%
Somerset 1497 153 10%
Cornwall 1009 139 14%
Suffolk 1449 120 8%
Oxfordshire 783 119 15%
Northumberland 978 101 10%
Lancashire 1473 75 5%
Cumbria 1892 69 4%
Gloucestershire 938 60 6%


The ten councils in Britain with the highest proportion of substandard bridges are:

Local Authority Number of bridges Number of substandard bridges Proportion of substandard bridges
Hammersmith and Fulham 4 2 50%
Liverpool 38 15 39%
Kingston upon Thames 11 4 36%
Brent 43 15 35%
Southend-on-Sea 64 22 34%
Barking and Dagenham 58 18 31%
Southampton 22 6 27%
Kensington and Chelsea 4 1 25%
Conwy 293 58 20%
Wolverhampton 58 10 17%


In the January 2021 floods caused by Storm Christoph washed away Llanerch Bridge in North Wales which had been built in the 1800s.

Disruption continues in London after restrictions were imposed on the 133-year-old Hammersmith Bridge over the Thames in London, first in April 2019 when it was closed to motorised vehicles, and then in August 2020 when it was also closed to pedestrians, cyclists and river traffic after microcracks were found in the cast iron pedestals at each end of the bridge that support the suspension structure. The work required to reopen the bridge to vehicles is estimated to cost £141 million.

Another example of the chaos caused when a bridge fails was the congestion that arose following the closure of part of the A52 Clifton Bridge over the River Trent in Nottingham in February 2020 after corrosion was found to have affected steel reinforcing rods. Repairs to the bridge – managed by Highways England – include adding external strengthening measures and will not be complete until the end of 2021.

Whilst no local authority manages structures directly technically comparable with the Morandi Bridge that collapsed in Genoa in August 2018, between them they do have a number of so-called post-tensioned (PT) bridges with hidden cables.

These PT bridges require intrusive inspections (Post-Tensioned Special Inspections or PTSIs) that can cost £100,000 each.

The number of local-authority managed PT bridges and how many require inspections:

Local Authorities that have PT bridges Total number of PT bridges Bridges that have had PTSIs in the last 18 years Bridges that require but have not had PTSIs in last 18 years Estimate of funding required for the additional PTSIs
105 675 297 293 £22.4m


The RAC Foundation also asked national roads authorities about their bridges:

Number of bridges Number of substandard bridges Proportion of substandard bridges
Highways England 9,392 95 1%
Transport Scotland 2,615 33 1%
Welsh Assembly 1,269 103 8%
